22 | Wiring diagram
274 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
Name Function Sheet
E147 OverheadLight 11
E522 Rightrearheadlight 10
E524 Platelightheadlight 10
E526 Leftfrontheadlight 10
E548 Leftrearheadlight 10
E551 Rightfrontheadlight 10
F1 OUTRIGGERSCONSENTRELAY 6
F10 FUSE+15SERVICESLIGHTINGSWITCHES 3
F11 FRONTSIDELIGHTSFUSERIGHTANDREARLEFT 10
F12 LICENSEPLATELIGHTSANDHEADLIGHTSFUSE 10
F14 ANTITIPPINGSYSTEMFUSE 7
F15 FUSE+15RADIOCONTROLSWITCHANDROTATINGLAMP 2
F16 STOPLIGHTSMICROSWITCHFUSE 10
F17 WORKLIGHTSSWITCHFUSE 11
F18 FUSE+15RADIOREMOTECONTROL 2
F184 Heatingselectorfuse 12
F19 FUSE+15BASKETKEY 2
F2 FUSE+30WARNING 10
F20 ELECTRICWINDOWRELAYFUSE 13
F21 FUSENOTUSED 13
F22 WORKLIGHTSRELAYFUSE 11
F23 FUSE+30COLUMNSWITCHLIGHTSANDOVERHEADLIGHTSWITCH 10
F24 OPTIONALPNEUMATICBRAKINGRELAYFUSE 13
F25 FUSE+30ALGATOOL 5
F26 FUSENOTUSED 13
F27 REVERSEGEARLIGHTANDBUZZERFUSE 3
F28 30°BOOMCONSENTRELAYFUSE 8
F29 BASKETWARNINGLIGHTCONSENTRELAYFUSE 8
F3 LOWBEAMLIGHTSFUSE 10
F31 TRANSMISSIONDISCONNECTFUSE 3
F32 SUPPLYRELAYFUSEUDCIDANFOSS 8
F34 OPTIONALSUPPLIESFUSE 13
F35 FRONTELECTRICWINDOWMOTORFUSE 10
F36 FUSE+15REARELECTRICWINDOWRADIOANTENNA 11
F37 FUSENOTUSED 13
F38 TRAILERANDREARSVSELECTORBUTTONFUSE 9
F39 FUSE+15SENSORS 5
F4 POWERSOCKETFUSE 11
F40 BOOMHEADFUSE 9
F41 FUSE+15MUSHROOMHEADEMERGENCYPUSHBUTTON 2
F42 FUSE+15ANTIRESTARTSTARTERGEARSHIFTERLEVERSUPPLY 2
F43 INCHINGMICROSWITCHFUSE 2
F5 HIGHBEAMLIGHTSFUSE 10
