Dieci SAMSON AGRI MAX - Page 275

Wiring diagram | 22
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 275
Name Function Sheet
F50 FuseVPMC2M 7
F51 Evaporatorfanfuse 12
F540 Mainfuse 1
F6 FUSENOTUSED 13
F693.1 Startfuse50A 1
F693.2 Preheatingfuse 1
F7 WORKLIGHTSRELAYFUSE 11
F755 Generalfuse2 1
F8 HORNRELAYFUSE 10
FG1 Alternatorfuse 1
G0 BATTERY 1
G529 Alternator 1
K1 STARTERANTIRESTARTCONTROLUNIT 2
K10 OUTRIGGERSCONSENTRELAY 6
K11 STARTUPFROMBASKETRELAY 2
K12 SERVICESCONSENTRELAY 1
K13 LEVELLINGFROMANTITIPPINGCONSENTRELAY 6
K14 EXTENSIONRELAYCONSENTRELAY 6
K15 NEUTRALGEARRELAY 3
K153 Servicesrelay 1
K16 TIMERCONTROLUNITRELAY 3
K17 ENGINESTOPRELAY 1
K18 OPTIONALPNEUMATICBRAKINGRELAY 13
K19 LEFTREARWORKLIGHTRELAY 11
K2 TIMERCONTROLUNIT 3
K20 RELAYNOTUSED 13
K21 BASKETWARNINGLIGHTCONSENTRELAY 8
K22 30°BOOMCONSENTRELAY 8
K23 SUPPLYRELAYUDCIDANFOSS 8
K24 TRANSMISSIONDISCONNECTRELAY 3
K25 2ndPUMPANDDEADMANRELAY 8
K26 LOWBOOMRELAY 8
K27 30°BOOMRELAYCONSENTRELAY 8
K28 AUXPUMPSVRELAY 8
K29 REVERSINGLIGHTSANDREVERSINGBUZZERRELAY 3
K3 ELECTRICWINDOWRELAY 13
K30 FORWARDSGEARRELAY 3
K302 Negativeneutralsignalrelay 3
K31 REVERSEGEARRELAY 3
K4 ELECTRICWINDOWRELAY 13
K5 HORNRELAY 10
K530 Startuprelay 1
K547 Thermostarterrelay 1
