22 | Wiring diagram
276 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
Name Function Sheet
K6 FRONTWORKLIGHTRELAY 11
K631 FILTERPREHEATINGRELAY 1
K7 RELAYNOTUSED 13
K8 HIGHBEAMLIGHTSRELAY 10
K9 LOWBEAMLIGHTSRELAY 10
M112 FRONTWINDOWWIPER 10
M117 FRONTWINDOWWASHER 10
M119 REARWINDOWWASHER 11
M122 Rearwipermotor 11
M129 HEATINGMOTOR 12
M133 Condenserfan 12
M152 Pneumaticseat 13
M179 Electricwindow 13
M195 Condenserfan2 12
M520 Startupmotor 1
M521 Airconditionedcompressor 12
P101 Instrument 1
P149 Rightdiffuser 11
P150 Rightdiffuser 11
P296 KUBOTAGLOWPLUGWARNINGLIGHT 2
P328 IVECOGLOWPLUGWARNINGLIGHT 2
P502 Reversegearbuzzer 10
P503 Horn 10
Q131 REARSOLENOIDVALVES 9
Q507 LEFTFRONTOUTRIGGERDESCENTSOLENOIDVALVE 6
Q508 LEFTFRONTOUTRIGGERLIFTINGSOLENOIDVALVE 6
Q509 LEFTFRONTOUTRIGGERDESCENTSOLENOIDVALVE 6
Q514 OUTRIGGERSGENERALSOLENOIDVALVE 6
Q515 RIGHTFRONTOUTRIGGERLIFTINGSOLENOIDVALVE 6
Q516 1stmanualgearSV 3
Q518 LEFTLEVELINGSV 6
Q519 RIGHTLEVELINGSV 6
Q521 ARMHEAD,FANREVERSE,RADIATOR2ndMANUALGEAR 3
Q523 ARMHEAD,FANREVERSE,RADIATORPARKINGBRAKE 3
Q527 FORWARDGEARSV 3
Q528 REVERSEGEARSV 3
Q536 Enginestop 1
Q597 HYDRAULICPOWERREDUCTIONSV. 9
R218 A/Cpotentiometer 12
R233 Acceleratorpedal 7
R510 GLOWPLUGHEATINGELEMENT 5
R533 Filterpreheater 1
S0 BATTERYISOLATOR 1
