8 | Components description
130 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
Installation Diagram Switch description
Standard hydraulic socket
+ Additional hydraulic socket
+ Electrical contact / Second
additional hydraulic coupler
0Standardhydraulicsocket
1Electricalcontacton(Incasetheplug
ofthevalveisconnectedtothesocket
of the electrical contact, Second
additionalhydrauliccouplerisenabled)
2Additionalhydraulicsocket
