Components description | 8
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 145
ThemaximumCapacityoftheequipmentisalsoreportedbythestickerplacedontheequipment
itself.
5
Boom angle
Theboomangleisindicatedbytheinclinometerontheleftsideattheendoftheboom(ifany),or
onthedisplayoftheantitippingdevice(ifpresent).
6
Boom extension
Theboomextensionisindicatedbylettersofthealphabet(“A”,“B”,"C","D",etc...).Thesamelettersare
shownasstickersontheboomextension,sothattheuserinthecabcanknowtheboomextension
byreadingthelettersonit.
7
Machine operating mode
Formoreinformation,refertothe"Capacitydiagramslegend"chapter.
8
Load height from ground
9
Horizontal distance of the machine load
10
Load weight
11
Machine position
8.18.1.2 Use the capacity diagrams
Thecapacitydiagramsindicatetheareasinwhichitispossibletooperatewiththemachineandloadinsafe
conditions.
DANGER
Danger of tipping.
Operating the machine without observing the Capacity diagrams related to the equipment installed may
result in hazardous conditions, up to the tipping limit and the operation of the Anti-tipping device.
Thewholeworkingareaoftheboomisdividedintotheseareas
(position “1”, fig. 1504651). Each area corresponds to a
maximumcapacity.Theareaclosesttothemachinewillhavea
capacityequaltothemaximumloadingcapacityofthemachine;
asmovingawayfromthemachine,themaximumcapacityofthe
areasdecreases.
Beforestartingtowork,itisnecessarytoknow:
– Loadweight
– Heightfromgroundatwhichtheloadmustbehandled
– Distance from the machine at which the load must be
handled
Locate the area of the capacity diagram, showing a value just
abovetheweightoftheloadtobehandled;forexampleifthe
loadshouldweigh1.5tons,theareatowhichitisnecessaryto
referistheareawithacapacityof2tons(position“1”).
1
150465-1
