Dieci SAMSON AGRI MAX - Page 175

Agriculture components description | 9
DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 175
The pickup hitch (fig. 1505031) is placed in the rear of the
vehicle and allows connecting the trailer to the vehicle directly
fromthecab.
TousethePickuphitchitisnecessarytofollowthisprocedure
(fig.1505032):
1. SelecttherearhydraulicsockettowhichthePickuphitchis
connectedthroughtheselector"1".
2. Pullthesafety release "2"inthecab (theleverpositioncan
varydependingonthemodelofthevehicle).
3. Move the services roller on the joystick forward to bring
downthePickuphitch.
4. Slowly reverse the vehicle to place the Pickup hitch under
thedrawbarofthetrailer.
5. MovetheservicesrolleronthejoystickbacktoliftthePickup
hitchandhookthetrailer.
6. Liftthehookuntilthesafetylocksnaps.
7. Driveslowlytocheckthatthehookingoccurredsuccessfully.
1505033
