Safety devices | 7

DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A 65

SIGNAL CODE DESCRIPTION

AXA2708 Typeofoilusedinthehydraulicsystem.

SIGNAL CODE DESCRIPTION

AXA1428 Indicatesthetirepressure

AXA1808 Indicatesthemaximumguaranteedsoundpower

AXA2227 Tiresmaximumloadontheground(R.maxdaN=)10000

AXA1920 IndicationoftheVarioSystemEVO2transmissionpotentiometers
