8 | Components description
78 DOCMA0000006‐UK ﴾ENG﴿ ‐ Samson FPT 3A
8.1.13.1 Direction indicators
Movethelever(fig.1504021):
– Towardsyourselftoindicateacurvetotheright(R).
– Forwardtoindicateacurvetotheleft(L).
The indicators only work when the ignition switch is in the
positionofinstrumentationon.
The indicator light “1” on the central instrument panel will
activatethedirectionindicators.
1
150402-1
CAUTION
Push the multifunction lever in stand-by position after making the turn, return to the neutral position is
not automatic.
8.1.13.2 Horn
Pressthe button on the end of the lever "1" (fig. 1504031), to
activatethehorn.
1
150403-1
8.1.13.3 Front window wiper
Turning the knob to "1" (fig. 1504041) activates the front
windowwiper.
The arrow "2" indicates which window wiper mode "3" is
currentlyactive:
– 0Off
– ISlow
– IIFast
2
3
1
4
