Duplo DC-616 Service Manual

S2-Y1540
105
4
Chapter 4 6 Cutter Section
-0
6 Cutter Section
1. Perform the operation check in HELP Mode: 29.
2. Feed the test paper through the machine applying the
Service person JOB.
3. Adjust the slide installation position (skew).
4. Adjust the cutting position in HELP Mode: 46.
(1)Cutter motor adjustment
1. Feed the test paper through the machine applying the
Service person JOB.
2. Check the sensor operation in HELP Mode:11, 26.
(2)Cutter home position sensor adjustment
(HELP Mode : 29→P.148)
(HELP Mode : 46→P.153)
(HELP Mode : 11→P.137)
(HELP Mode : 26→P.145)
