Chapter 9 1 Main Menu of PC Controller
186
S2-Y1540
1 Main Menu of PC Controller
The following screen appears when PC Controller is run.
Select each sub menu to be set from this main menu screen.
No. Item Function
1
WIZARD
Create a JOB in Wizard format.
A preview of the JOB being created is displayed. Create the JOB
while checking the input details.
2 DIRECT
Directly input the number value to create a JOB.
Use this to create a JOB rather than “WIZARD” when the
dimensions are already fi nalized.
3 UPLOAD Read the JOB from the DC-616 and save in computer.
4 SETTING This is used to set the default values of the PC Controller.
5 MAINTENANCE
For service person use only. This is used for setting the machine
etc. Password is required to access.
6 SELECT This reads the saved JOBs on the DC-616. Select one from them.
7 Job Detail Input JOB details are displayed.
8 DOWNLOAD This sends the JOB saved on the computer to the DC-616.
9 OPEN This opens the saved JOB on the computer.
10 Preset Count This presets the number of sheets to be processed for the JOB.
-0
6
7
8
9
1
2
3
4
5
10
11
12
13
14
15
16 17
18
19
20
25
24
21
22
23
