Duplo DC-616 Service Manual

178
Chapter 8 2 Service Person JOBs
S2-Y1540
2 Service Person JOBs
Use to check the
parallelity of the
right margin.
Use to adjust the
vertical enlargement
(magnifi cation)
of H-52.
(using 650 exclusive
paper)
H-46: Use to cut.
H-47: Use to adjust
the parallelity and
distance of the crease.
H-48: Use to adjust the
depth of the crease.
H-49: Use to adjust
the slit position.
H-50: Use to adjust
the position of the
gutter defl ector
guide.
JOB Name MARGIN CK H-52 CK1 CUT&CRE CK SLIT CK GUTTER CK
Paper size 297×420(A3) 320 x 650 297×420(A3) 297×420(A3) 297×420(A3)
JOB number 81 82 83 84 85
PAPER WIDTH 297 320 297 297 297
TOTAL LENGTH 420 650 420 420 420
Side Mark 00000
Lead Mark 00000
SLIT1 25 0 25 25 5
SLIT2 285 0 285 275 285
SLIT3 0 0 0 75 95
SLIT4 0 0 0 225 195
SLIT5 0 0 0 125 100
SLIT6 0 0 0 175 190
CUT01 0 20 20 0 0
CUT02 0 570 0 0 0
CUT03 00000
CUT04 00000
CUT05 00000
CUT06 00000
CUT07 00000
CUT08 00000
CUT09 00000
CUT10 00000
CUT11 00000
CUT12 00000
CUT13 00000
CUT14 00000
CUT15 00000
CUT16-25 00000
CRE.01 0 0 120 0 0
CRE.02 00000
CRE.03 00000
CRE.04 00000
CRE.05 00000
CRE.06 00000
CRE.07 00000
CRE.08 00000
CRE.09 00000
CRE.10 00000
CRE.
11-20 00000
PERF1 00000
PERF2 00000
AIR KNIFE OFF OFF OFF OFF OFF
SUCTION POWER MAX MAX MAX MAX MAX
REG. MARK OFF OFF OFF OFF OFF
SLIT GUIDE ON ON ON ON ON
AUTO CUT ON ON ON ON ON
CREASE DEPTH MID MID HIGH MID MID
SPEED FAST FAST FAST FAST
-0
