112
Chapter 5 4 Recommended Parts List
S2-Y1540
4 Recommended Parts List
No. Part No. Part name
MTBF
Remarks
1 S2-A114* BELT 1 million sheets Coated paper/230 gsm
2 AJ233 TIMING BELT -
3 AK049 ROLLER CHAIN -
4 N4-K212*
SEPARATER PLATE
-
5 P9-F104*
UPPER BLADE
2 million sheets Coated paper/230 gsm
6 P9-F107*
LOWER BLADE UNIT
2 million sheets Coated paper/230 gsm
7 P9-F121* NUT -
8 P9-F128* ROLLER -
9 S2-J210* CUTTER UNIT 1 million sheets Coated paper/230 gsm
10 S2-K111* CREASER UPPER BLADE 1 million sheets Coated paper/230 gsm
11 S2-K102* CREASER LOWER BLADE 1 million sheets Coated paper/230 gsm
12 AJ232 TIMING BELT -
13 AJ044 TIMING BELT -
14 AJ301 TIMING BELT -
15 AJ146 TIMING BELT -
16 AJ230 TIMING BELT -
17 AJ231 TIMING BELT -
18 S2-N101* DRIVING ROLLER 1 million sheets Coated paper/230 gsm
19 S2-N102* ROLLER CHAIN 1 million sheets Coated paper/230 gsm
20 U7-Q515*
PERFORATION BLADE
250,000 times
high-quality paper(230 sm)
21 BZ008 MOTOR DRIVER -
22 CA021
PHOTO MICROSENSOR
-
23 CA032
REFLECTIVE SENSOR
-
24 CA033
PHOTOINTERRUPTER
-
25 CA046
PHOTO MICROSENSOR
-
26 CA059
PHOTOINTERRUPTER
-
27 LA048 MICRO SWITCH 500,000 times
28 UA040 SWITCHING POWER SUPPLY 100,000 times
29 UD028 RELAY -
30 UJ040 RELAY -
31 P9-X107* PHOTOINTERRUPTER -
32 L5-X104* MOTOR -
33 M7-X104* MOTOR -
34 U7-X101* DC BLOW -
35 S2-X107* DC BLOWER -
36 P6-X101* DC SOLENOID -
37 S2-V500* MAIN PCB UNIT -
38 S2-V311* PANEL PCB UNIT -
39 S2-V321* DRIVING PCB UNIT -
40 R8-V341* USB PCB Unit -
-0
