Chapter 8 1 Position and Function of Electronic Parts
8
S2-Y1540
6. Others
No. Part Name
1 SSR
2 Fuse
3 Compressor
4 Relay PCB UNIT
5 Appliance inlet
6 Varistor
7 Terminal blocks
5
1
4
6
3
2
7
8
-0
