118
Chapter 6 1 Troubleshooting
S2-Y1540
-0
(6) When “J6 Exit tray” is displayed
step
cause/failed
area
check item if action
see
page
1
Inside the
machine
Paper jam in the machine
(stacker tray unit or waste
box unit)
YES
Remove the paper inside
the machine.
-
NO Go to step 2. -
2
PPS4/Margin jam
sensor
Check that the margin jam
sensor and PPS4 work
properly in HELP Mode: 11.
YES Go to step 3. -
NO
• Clean the sensor.
• Replace the sensor.
89
3
Connector,
Main PCB unit
Check that the PPS4 and
margin jam sensor are
connected to #4 connector of
the main PCB properly.
YES Reconnect properly. -
NO Replace the main PCB Unit. 97
(7) “E00 Main-Panel” is displayed
step
cause/failed
area
check item if action
see
page
1
Main PCB/
control panel
Check that the connection
between the main PCB
(CN6) and the board of
control panel (CN3) is
correct.
YES Reconnect properly. -
NO Go to step 2. -
2
Main PCB/
control panel
Check that the LED works
properly on the control
panel in HELP Mode:16.
YES Replace the main PCB Unit. 97
NO Replace the panel PCB Unit 96
(8) When “E01 CCD” is displayed
step
cause/failed
area
check item if action
see
page
1 CCD
Try reading out the
adjustment test paper.
NG
Replace the main PCB or
CCD.
97
68
-0
(HELP Mode : 11P.137)
(HELP Mode : 16P.140)
