Duplo DC-616 Service Manual

6
119
Chapter 6 1 Troubleshooting
S2-Y1540
-0
step
cause/failed
area
check item if action
see
page
1
Elevator lower
limit switch
Check that the elevator
lower switch works properly
in HELP Mode: 17.
YES Go to step 2. -
NO Replace the switch. 62
2
Elevator upper
limit switch
Check that the elevator
upper limit switch works
properly.
YES Go to step 3. -
NO Replace the switch. 62
3 Drive PCB
Check the adequate 24 V
output power at #1 and 2
terminal of CN5.
YES Replace the elevator motor. 63
NO
Replace the drive/power
source PCB.
96
97
(9) When “E02 Elevator” is Displayed
step
cause/failed
area
check item if action
see
page
1
Creaser lower
blade HP
sensor
Check that the creaser
lower blade sensor works
properly in HELP Mode: 28.
YES Go to step 2. -
NO
• Clean the sensor.
• Replace the sensor.
87
2
Creaser lower
blade ENC sensor
Check that the creaser
lower blade ENC sensor
works properly in HELP
Mode: 28.
YES Go to step 3. -
NO
• Clean the sensor.
• Replace the sensor.
88
3
Connector, drive
PCB
Check that the creaser
lower blade HP sensor is
connected to #3 connector
of the main PCB properly.
YES Reconnect properly. -
NO Replace the main PCB Unit.
97
(10) When “E03 Crease lower” is Displayed
step
cause/failed
area
check item if action
see
page
1 Main PCB
Check that an error
message is displayed
even if the power is turned
on again.
YES Replace the main PCB Unit. 97
(11) When “E04-06 Memory error” is Displayed
-0
(HELP Mode : 17→P.141)
(HELP Mode : 28→P.147)
