Duplo DC-616 Service Manual

Chapter 1 2 Part Names and Their Functions
S2-Y1540
16
3. Appearance (Ejection side)
-0
No. Name Function
1 Perforation unit Perforates parallel to the document feed direction.
2 Side guide Receives the processed documents.
3 Back guide Receives the processed documents.
4 USB terminal Used for the connection to your computer on PC Controller using.
5 AC inlet Connect the power cord here.
6 Power switch Press to switch the power on and off.
1
6
5
4
3
2
