S2-Y1540
Continuously pressing the RETURN key and the CURSOR (Down) key simultaneously can
reset the machine to the standby mode.
2 Accessing the HELP Mode
3 Finishing the HELP Mode
4 Setting the Other HELP Mode No.
5 Accessing the Service Person JOB
1. When the machine is in use, put it in the standby mode and turn OFF the power switch before
accessing the HELP Mode.
2. Turn on the power switch, and hold down the (Left) and (Right) JOG keys
simultaneously.
In about 10 seconds, “00: ROM VERSION” appears on the display with the beep sound.
3. Input the relevant “HELP Mode No.” that you want to check or change by the NUMERIC keys.
e.g.: To access the HELP Mode “H-11”, input the number by pressing “1”, “1”.
1. When the machine is in use, put it in the standby mode and turn off the power switch before
accessing the HELP Mode.
2. Turn on the power switch while pressing the CURSOR (Up) key and the CLEAR key
simultaneously.
The machine is put in the standby mode with the “pip” sound.
3. Input the “Service person JOB No.” to be checked by using the NUMERIC keys.
e.g.: To access the Service person JOB “81”, input the number by pressing “8”, “1”.
4. Press the TEST key, and the JOB will be implemented.
Turn off the power switch to fi nish the HELP mode.
Press the STOP key to return to the selection screen of the HELP mode.
Input the “HELP Mode No.” that you want to check or change by the NUMERIC keys.
4. Press the <START> key. The “HELP Mode” specifi ed in 3 above is displayed.
Follow the procedure described under the corresponding “HELP Mode No.”
Alternatively, “HELP Mode No.” is selected by using the Cursor (Up/Down) key. Holding down
the key can select HELP Mode automatically as well.
Chapter 7 2 Accessing 3 Finishing the HELP Mode 4 Setting the Other HELP No. 5 Accessing the Service Person JOB
