Chapter 8 1 Position and Function of Electronic Parts
8
S2-Y1540
7. USB PCB Unit (R8-V347*)
8. Fuse (0216002XP)
CAUTION
Fuse
: Use the proper type of fuse when replacing. Otherwise, fi re may occur.
CN2
CN1
-0
Rating of fuse : 250 V, 2 A
