131
Chapter 7 6 HELP Mode
7
S2-Y1540
H00 Version ck.
▼
Version ck
H00 Version ck.
▼
Main:V
XX.XX
Total:V
XX.XX
Reset
:
XXXXXXXX
Preparing for
software update
2-2. USB version upgrade
The USB Serial Converter is a software necessary for upgrading product via computer.
Operating system: Windows 8 (32bit/64bit)
Windows 7 (32bit/64bit)
Windows VISTA (32bit/64bit)
Windows XP Professional/Home Edition
Windows 2000 Professional
Interface: USB port (USB2.0/1.1)
The USB Serial Converter is not available in Macintosh.
1. When the machine is in use, put it in the standby mode and turn
off the power.
2. Connect your computer and the DC-616 with the USB cable.
3. Turn on the power switch.
Hold down the (Left) and (Right) JOG keys simultaneously.
“H00 : Version ck” appears on the LCD panel with beeping sound.
4. Press the <START> key to check the version of the main PCB
unit and the panel PCB unit.
5. Press the SET key to enter upgrading mode.
Click [
Cancel
] if “Completing the device driver installation
wizard” dialog appears on your computer.
6. Click [
Duplo download utility
] folder, and double-click [
Duplo
download utility. exe
].
REFERENCE
-0
To Next Page
