Duplo DC-616 Service Manual

1
Chapter 1 1 Specifi cations
S2-Y1540
13
The specifi cations are subject to change without prior notice.
Paper Curl
Due to the automated slitter function, the paper path of the DC-616 is sensitive to paper curl.
If paper curl is causing paper jams, the following are suggestions for remedying the problem:
1. Adjust the printing devices de-curler (if available).
2. Manually de-curl the stock before loading in the fe tray.
3. Turn the paper over (reprogramming the job may be necessary).
4. Use different paper stock.
-0
Model name DC-616
Functions 80 job memory
Test feed
Skew adjustment
Slitter guide
Auto cut
Apply shrinkage
Adjust all
Cleaning mode
Automatic job setup by reading barcode (CCD is optional on “115V”
and “230V Asia Oceania” models.)
Image shift compensation by reading REG mark (CCD is optional on
“115V” and “230V Asia Oceania” models.)
Options Air knife (optional on “230V Asia Oceania” model)
Double feed detection (optional on “115V” and “230V Asia Oceania”
models)
CCD (standard on “115V PRO” and “230V EMEA” models)
Card stacker (optional on “230V Asia Oceania” model)
Perforation unit (optional on “115V” and “230V Asia Oceania” models)
Long paper tray
PC am mount (standard on “115V PRO” model)
PC controller software (standard on “115V PRO” model)
USB (B TYPE CONNECTOR)
Compatible OS:
Windows XP Professional/Home edition (x86 32bit only)
Windows Vista Ultimate/Business/Home basic/Home premium
Windows 7 Ultimate/Professional/Home premium
Windows 8 Professional/Enterprise
Power supply 115 VAC, 60 Hz 230 VAC, 50/60 Hz
Power consumption 115 V: current consumption 1.5 A (standby: 0.25 A)
power consumption 190 W (standby: 26 W)
230 V: current consumption 0.7 A (standby: 0.22 A)
power consumption 190 W (standby: 26 W)
Dimensions In use: 1610 (W) × 625 (D) × 1060 (H) mm
In use with max paper: 2025 (W) × 625 (D) × 1060 (H) mm
Stored: 975 (W) × 625 (D) × 1060 (H) mm
Packed: 1140 (W) × 770 (D) × 1360 (H) mm
Machine weight 115 V: 145 kg (Gross weight: 178 kg)
115 V PRO: 155 kg (Gross weight: 188 kg)
230 V EMEA: 150 kg (Gross weight: 183 kg)
230 V Asia Oceania: 140 kg (Gross weight: 173 kg)
Operating temperature 10–30 degrees (Celsius) (50-80 degrees (F))
Operating humidity 40%–70% RH (No condensation)
Storing temperature 5–35 degrees (Celsius)
Storing humidity 20%–70% RH (No condensation, No exposure to salt)
Operating altitude Max 1000 m ALT
Safety standard UL, CE, VCCI
