87
Chapter 3 8 Creaser Section
3
S2-Y1540
1. Remove the cover F.
2. Take out the two screws, and remove the motor with
the bracket.
1. Remove the cover F.
2. Take out the two screws, and remove the sensor
with the bracket.
(5) Removing the Crease Lower Blade Motor
(4) Removing the Crease Lower Blade Home Position Sensor
3. Remove the sensor from the bracket.
* Adjustment required at the time of installation
Gear
3. Loosen the hexagon socket set screw, and remove
the gear.
4. Take out the three screws, and remove the motor
from the bracket.
* Adjustment required at the time of installation
(See→P.108)
(See→P.52)
(See→P.52)
(See→P.106)
Screw
-0
To Next Page
