Folder

142 Service Instructions 745-35-10 S/745-35-10 A - 02.0 - 04/2017

Fig. 124: Aligning the folder with the needles (2)

3. Loosen screws (4) and (6).

4. Shift the folder (5) in sewing direction.

5. Tighten screws (4) and (6).

(4) - Screw

(5) - Folder

(6) - Screw

④

⑤

⑥
