Programming

222 Service Instructions 745-35-10 S/745-35-10 A - 02.0 - 04/2017

Set return of transport clamp

 The display switches to Return of transport clamp.

Fig. 193: Set return of transport clamp

To set the transport clamp return:

1. Press the desired button.

2. Enter the desired value using the numeric keypad.

 Confirm with OK.

Symbols Meaning

Activate without transport

Activate transport up to stacking position

• 1 mm - 100 mm

Activate transport up to loading position
