Programming

Service Instructions 745-35-10 S/745-35-10 A - 02.0 - 04/2017 225

Select transport clamp quick adjustment

(745-35-10 A only)

The display switches to Select transport clamp quick adjustment.

Fig. 196: Select transport clamp quick adjustment

To set the transport clamp quick adjustment:

1. Press the desired button.

Symbols Meaning

Left in, right in (double pipe)

Left out, right in (single pipe left)

Left in, right out (single pipe right)

Left out, right out
