Programming

Service Instructions 745-35-10 S/745-35-10 A - 02.0 - 04/2017 237

To adjust the settings in the service menu:

1. Press the desired button.

 The user interface for setting the desired item is displayed.

Machine configuration

Important

The Machine configuration menu is protected with a password.

You use this menu to adjust basic machine parameters. The password is

25483.

 The display switches to Machine config.

Fig. 204: Machine configuration

Only available to Dürkopp Adler

Maintenance information  p. 290

Set language, button beep and user password  p. 292

Button Meaning
