Machine head

24 Service Instructions 745-35-10 S/745-35-10 A - 02.0 - 04/2017

Removing the head cover

Fig. 12: Removing the head cover

To remove the head cover:

1. Loosen the screws (1).

2. Remove the head cover (2).

(1) - Screws (2) - Head cover

①

②

①
