NR in the data part of a parameter indicates no reading.
NP in the data part of a parameter indicates a parameter that is not present.
9.4.1 Normal menu
This menu is displayed when the PDT is rst plugged into the pump, or accessed by
pressing the NORMAL buon. Up to four parameters are displayed. Scroll by pressing
the UP/DOWN keys.
Table 29
Normal menu
Descripon
Typical display
Serial Number S/N 1234567
Control Holder NONE IN CONTROL
Dry Pump current DP CURRENT 1.1 A
Booster current MB CURRENT 1.1 A
By default, the four parameters displayed in the normal menu are as shown in Table:
Normal menu. It is possible to change the parameters displayed, refer to How to set up
the PDT display on page 133.
9.4.2 Status menu
Press the STATUS buon to enter. Scroll by pressing the UP/DOWN keys. Press CANCEL to
exit back to the Normal menu.
If a device is not ed the associated parameters will not be displayed. Parameters
displayed:
Table 30
Typical display
Descripon
Typical display
Serial number S/N 1234567
Control holder NONE IN CONTROL
Dry pump current DP CURRENT 1.1 A
Booster current MB CURRENT 1.1 A
Green mode state Green Mode STATE O
Inlet isolaon valve open/closed state ISOL VALVE Open
Dry pump stator reference temperature TCS REF 100 C
Dry pump temperature DP TEMP 100 C
Dry pump exhaust stage temperature DP EXH STG 63 C
Dry pump end cover temperature DP E/C TEMP 100 C
Booster temperature MB TEMP 100 C
Booster end cover temperature MB EC TEMP 100 C
Nitrogen ow switch status N2 Supply OK
Dry pump power DP POWER 1.1 kW
Booster power MB POWER 1.1 kW
Dry pump speed in percent DP SPEED 100 %
Page 122
M58800880_H - Pump display terminal
