Edwards GXS Series

2.5 Electrical data
Table 7 Electrical data
Characteriscs GXS160 GXS160/1750 GXS250 GXS250/2600 GXS450 Units
Dry pump motor rang 7.5 7.5 7.5 7.5 11 kW
Mechanical booster
motor rang
- 4.5 - 7.5 - kW
Current rang
(200 - 230 V systems)
25 31 31 38 49 A
Current rang
(380 - 460 V systems)
11 14 14 20 26 A
Recommended branch
circuit protecon UL
(200 - 230 V systems)
30 40 40 50 60 A
Recommended branch
circuit protecon IEC
(200 - 230 V systems)
25 35 35 35 50 A
Recommended branch
circuit protecon UL
(380 - 460 V systems)
15 20 20 25 30 A
Recommended branch
circuit protecon IEC
(380 - 460 V systems)
15 15 15 20 30 A
Min cable size for 200 -
230 V systems (or
corresponding AWG size)
6 (8)* 6 (8)* 6 (8)* 10 (8) 10 (6)
mm
2
(AWG)
Min cable size for 380 -
460 V systems (or
corresponding AWG size)
6 (8)* 6 (8)* 6 (8)* 6 (8)* 6 (8)*
mm
2
(AWG)
Mains connector for 200 -
230 V systems
Han
®
K
4/4
Han
®
K 4/4
Han
®
K
4/4
Han
®
K 4/4 Han
®
K 4/4
-
Mains connector for 380 -
460 V systems
Han
®
K
4/4
Han
®
K 4/4
Han
®
K
4/4
Han
®
K 4/4 Han
®
K 4/4
-
Page 20
M58800880_H - Technical data
