Edwards GXS Series User Manual

Table 42 Smart stop opons menu
Opon Text on PDT line 2
Opons on PDT line 2 aer pressing
Enter
Smart stop enable/disable Enable/Disable... Enable/Disable
Time for pump to stop Stop me... Range 0 ‑ 3600 seconds in 60 second
steps*
Size of speed step changes Step size... Range 20 to 110 Hz*
Temperature to stop pump
once reached
Setpoint... Range 0-210 °C*
Time aer temperature is
reached before pump
stops
Sele me... Range 1-200 seconds*
* Scroll through the opons by pressing the UP/DOWN keys. Press ENTER to accept the
new seng. Press CANCEL to exit back into the Smart stop menu.
Press the UP/DOWN keys to select enable/disable and press ENTER to accept or CANCEL
to exit back to the Smart stop menu.
9.4.16 Speed control opons menu
Scroll by pressing the UP/DOWN keys. Press ENTER to open a sub menu or CANCEL to
exit back to the Set sequences menu.
Table 43
Speed control opons menu
Opon Text on PDT line 2 Opons
on PDT line 2 aer pressing Enter
Set speed control dry
pump
Dry pump... Select from:
Normal/PID
External Voltage
SIM protocol
Second speed
Set speed control
booster
Booster... Select from:
Normal
External Voltage
SIM protocol
Second speed
Set the second speed Second Speed...
Range 20 - 110 Hz*
* Scroll through the opons by pressing the UP/DOWN keys. Press ENTER to accept the
new seng. Press CANCEL to exit back into the Speed control menu.
9.4.17 Reset MicroTIM
Empes the MicroTIM conguraon set storage of any conguraons that have been
loaded there.
Page 129
M58800880_H - Pump display terminal
