3. The Second Speed input can be used to control the speed of either the dry pump or the
booster, this can be set using the SPEED CONTROL menus. Refer to How to control the
pump speed on page 144.
9.14.2 Conguring the channel 4 output
By default, the MCM MicroTIM channel 4 output is congured to show the status of the
isolaon valve (if ed). The user has the opon of conguring channel 4 to monitor the
status of system warnings, booster, nitrogen ow, water ow, exhaust pressure and
remote/local control.
From the MicroTIM menu, select Output 4... and then scroll down the menu and press
ENTER to select the output of choice.
Notes:
1. Only one output opon can be acve at a me.
2. Booster status is only available for combinaon systems that contain a dry pump and
booster.
3. Isolaon valve, nitrogen ow and water ow monitoring kits are available as oponal
accessories and status can only be monitored if ed.
9.15 How to run the booster independently from the dry pump
The booster can be set to run independently from the dry pump using the PDT. The
booster can then be controlled using the PDT, the MCM MicroTIM, the SIM protocol or
Probus.
If controlling the booster from the PDT or by using SIM protocol or Probus then the
booster start mode needs to be changed to 'manual' using the PDT. Refer to Seng the
booster to manual operaon on page 137 for the instrucons on seng the booster to
manual mode. Once in manual mode, the booster will operate independently from the
dry pump.
9.15.1 Run the booster manually using the PDT
To turn the booster on using the PDT, follow this procedure and refer to Figure: Booster
commands menu:
1.
From the SETUP menu, select Command Menu... (requires an access code: 202).
2.
Scroll down and select MB...
3.
Scroll down and select On.
Figure 76 Booster commands menu
Page 158
M58800880_H - Pump display terminal
