3.5 Leak test the dry pumping system
Figure 6 Interspool connecons on the pump/booster combinaon systems
ID Part idencaon
1 1/4 inch BSP inlet port (available on dry pumping systems with light duty gas
module only)
2 3/8 inch BSP port
3 Interspool
4 3/8 inch BSP port
WARNING:
Leak test the dry pumping system aer installaon and seal any leaks found to
prevent leakage of dangerous substances out of the dry pumping system and leakage
of air into the dry pumping system.
The pump and booster combinaon systems have an interspool which has several ports
that can be used for leak checking purposes. Remove the right hand side panel.
Note:
For further informaon on the leak tesng, contact us or the supplier for advice.
3.6 Electrical supply
WARNING:
Ensure that the electrical installaon of the dry pumping system conforms to all local,
regional and naonal safety requirements. It must be connected to a suitably fused
and protected electrical supply and a suitable earth (ground) point.
Page 37
M58800880_H - Installaon
