Edwards GXS Series User Manual

Figure 10 Electrical connector locking mechanism for the GXS160, GXS250 and GXS450 systems
CS/1064/A
12
3
4
5
1. Electrical connector locking mechanism 2. Pivot screw
3. Locking screw 4. Lever (2 o)
5. Protecve cover
1. Electrical connector locking mechanism 2. Pivot screw
3. Locking screw 4. Lever (2 o)
5. Protecve cover
Figure 11 Electrical connector locking mechanism for the GXS750 systems
CS/1065/A
1
2
3
4
1. Protecve cover 2. Lever (2 o)
3. Electrical connector locking mechanism 4. Locking nuts
1. Protecve cover 2. Lever (2 o)
3. Electrical connector locking mechanism 4. Locking nuts
3.7 Connect an addional RF earth (ground) (oponal)
If the dry pumping system will be operated in an area subject to high Radio Frequency
(RF) emissions, in accordance with a good RF installaon pracse, we recommend to:
▪
use a star washer to connect the end of the earth (ground) cable connected to the
dry pumping system inlet to one of the bolts that are used to secure the inlet
ange. Refer to Figure: Front view of the pumping system with the side exhaust and
skids ed, item 6.
▪
connect an addional earth (ground) cable to the RF earth (ground) stud. A
suitable low-impedance cable must be used (for example, braided cable). Refer to
Page 45
M58800880_H - Installaon
