Edwards GXS Series User Manual

Figure 8 The Harng Han® 100 A axial screw module cable-mounted connector
1. Low volt pin conguraon 2. High volt pin conguraon1. Low volt pin conguraon 2. High volt pin conguraon
A. Coding pin B. Mounng screw
C. View from cable side: connect protecve
earth into earth terminal
D. 4 mm hex (allen) key
E. Insert stranded wire
A. Coding pin B. Mounng screw
C. View from cable side: connect protecve
earth into earth terminal
D. 4 mm hex (allen) key
E. Insert stranded wire
Pin idencaon
Pin A1 Phase 1
Pin A2 Phase 2
Pin D1 Not connected
Pin D2 Phase 3
Torque sengs for connector pins
Cable size (mm
2
)
Maximum torque seng (Nm)
10 6
16 6
25 7
35 8
3.6.2 Customer connecon kit, combinaon low volts GXS750
Tools and equipment:
▪
No 1 Pozidrive screwdriver
▪
5 mm hexagonal allen key bit
▪
Torque driver set to 10 Nm
Page 43
M58800880_H - Installaon
