Edwards GXS Series User Manual

Table 2 General technical data
Pump
Characteriscs
Body dimensions
length x width x
height*
Mass
(excluding
packaging)
Noise level (at
ulmate with
a piped
exhaust)
Typical
vibraon level
at inlet
Inial force to
push the
pump†
Sustained
force to
push the
pump†
Pump inlet
ange
(bolted)
Exhaust
gas
outlet
Lubricant
volume
Units mm kg dB(A) mm/s kg force kg force litre
GXS160 1092 x 390 x 568 305 < 64 < 1.5 < 20 < 10
ISO63
‡
NW40 0.7
GXS160/1750 1092 x 390 x 830 475 < 64 < 1.5 < 20 < 10 ISO100 NW40 1.4
GXS250 1092 x 390 x 568 305 < 64 < 1.5 < 20 < 10
ISO63
‡
NW40 0.7
GXS250/2600 1092 x 390 x 830 515 < 64 < 1.5 < 20 < 10 ISO160 NW40 1.4
GXS450 1186 x 517 x 717 546 < 64 < 1.5 10 5 ISO100 NW50 1.8
GXS450/2600 1186 x 517 x 1031 760 < 64 < 1.5 16 6 ISO160 NW50 2.4
GXS450/4200 1186 x 517 x 1031 818 < 64 < 1.5 22 < 10 ISO160 NW50 3.3
GXS750 1622 x 517 x 717 679 < 70 < 1.5 15 5 ISO100
NW50
‡
2.8
GXS750/2600 1622 x 517 x 1031 918 < 70 < 1.5 22 < 10 ISO160
NW50
‡
3.5
GXS750/4200 1622 x 517 x 1031 976 < 70 < 1.5 22 < 10 ISO160
NW50
‡
4.3
* Refer to Installaon drawings on page 80.
† For dry pumping systems ed with oponal castors, measured in a laboratory on a level concrete surface.
‡ Refer to Connect the dry pumping system to the vacuum/exhaust system on page 31 for informaon relang to the exhaust size and length for GX750 dry
pumping systems.
‡ For MD+ variants, this ange size is ISO100 to accommodate high ow purge assembly.
