Part 2: Maintenance 4. Connector Pin Assignments
105
X50 Signal connector X51 Signal connector
No. Line color Connect to No. Line color Connect to
1A BLU/(WHT) X51-1 1 BLU/(WHT) X53-1
1B WHT/(BLU) X51-2 2 WHT/(BLU) X53-2
2A YLW/(WHT) X51-3 3 YLW/(WHT) X53-3
2B WHT/(YLW) X51-4 4 WHT/(YLW) X53-4
3A GRN/(WHT) X51-5 5 GRN/(WHT) X53-5
3B WHT/(GRN) X51-6 6 WHT/(GRN) X53-6
4A RED/(WHT) X51-7 7 RED/(WHT) X53-7
4B WHT/(RED) X51-8 8 WHT/(RED) X53-8
5A PPL/(WHT) X51-9 9 PPL/(WHT) X53-9
5B WHT/(PPL) X51-10 10 WHT/(PPL) X53-10
6A BLU/(BRN) X52-1
6B BRN/(BLU) X52-2
X52 Signal connector
7A YLW/(BRN) X52-3 No. Line color Connect to
7B BRN/(YLW) X52-4 1 BLU/(BRN) X53-11
8A GRN/(BRN) X52-5 2 BRN/(BLU) X53-12
8B GRN shield 3 YLW/(BRN) X53-13
4 BRN/(YLW) X53-14
5 GRN/(BRN) X53-15
6 GRN shield
