Epson WF-C5210 Service Manual

EPSON WF-C5790/WF-C5790a/WF-C5710/ET-8700/WF-C5210/WF-C5290/WF-C5290a Revision A
Disassembly/assembly Disassembly/Reassembly Procedures 527
Confidential
DISASSEMBLY FLOWCHART
E1
C1
Start
D1
A4
B3
F1
B1A1
E2
C2
D2 F2
B2A2
A3
E3
D3
F3
C3
E4 F4
D4
E5 F5
E6
F7
F6
Start
Paper Feed Detector
Lever (→P. 531)
Optional Paper Cassette
Unit (→P. 528)
Paper Cassette 2nd Assy
(→P. 528)
Optional Paper Cassette
Rear Cover (→P. 529)
Separation Roller
(→P. 530)
Rear Lower Cover Assy
(→P. 529)
E-ring (plastic)
(→P. 531)
One-way Gear
(→P. 532)
Torsion Spring 0.9
(→P. 532)
Vertical Feed Roller
(→P. 533)

Epson WF-C5210 Specifications

General

Print Resolution	4800 x 1200 dpi
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Operating System Support	Windows, Mac OS, Linux
Functions	Print
Ink Type	DURABrite Ultra Pigment Ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore
Monthly Duty Cycle	45, 000 pages
Paper Sizes	A4, A5, A6, B5, Letter, Legal, Envelopes
Display	2.4" color LCD
Print Speed	Up to 24 ppm (black/color)
Input Tray Capacity	250 sheets
