A Menu Structure FLUXUS G60x
UMFLUXUS_G6V4-2EN, 2011-03-29 171
selection of the transducer type
This display will only be indicated if no or spe-
cial transducers are connected.
When a Calculation Channel is Selected (Y, Z)
Calculation channels will only be available if the transmitter has more than one
measuring channel.
display of the current calculation function
selection of the calculation function
Program Branch Measuring
main menu: selection of the program branch
Measuring
activation of the channels
This display will not be indicated if the transmit-
ter has only one measuring channel.
input of the measuring point number
This display will only be indicated if Output
Options\Store Meas.Data and/or Seri-
al Output are activated.
activation/deactivation of the flow profile correc-
tion
This display will only be indicated if Special
Funct.\SYSTEM settings
\
Measuring\
Flow Velocity = uncorr. has been select-
ed.
input of the number of sound paths
This display will only be indicated if Special
Funct.\SYSTEM settings\Dialogs/
Menus\Sound Path = USER has been select-
ed.
cold start
resistant
Transducer Type
Standard
Calculation:
Y= A - B
>CH1< funct ch2
A - B
par >MEA< opt sf
Measuring
CHANN: >A< B Y Z
MEASUR  - .
A:Meas.Point No.:
xxx (↑↓← )
A:PROFILE CORR.
>NO< yes
A: Sound Path
2NUM
