172 UMFLUXUS_G6V4-2EN, 2011-03-29
FLUXUS G60x A Menu Structure
display of the transducer distance to be adjust-
ed between the inner edges of the transducers
This display will only be indicated if in Special
Funct.\SYSTEM settings\Dialogs/
Menus\Sound Path = user has been select-
ed.
bar graph S=, display of the amplitude of the
received signal
Program Branch Output Options
main menu: selection of the program branch
Output Options
selection of the channel whose output options
are to be defined
selection of the physical quantity
selection of the unit of measurement for the
physical quantity
activation of a temperature input
This display will only be indicated if the temper-
ature input T1 has been assigned to the chan-
nel in Special Funct.\SYSTEM settings\
Proc. inputs\Link temperature.
activation of a current input for an external tem-
perature measurement
This display will only be indicated if the input I1
has been assigned to the channel in Special
Funct.\SYSTEM settings\ Proc. in-
puts\Link other inp..
cold start
resistant
Transd. Distance
A:54 mm Reflex
par mea >OPT< sf
Output Options
Output Options ↕
for Channel A:
Physic. Quant. ↕
act. Volume flow
To Next Page
