Chapter 8 Advanced Copy Management
8.1 Advanced Copy Status
ETERNUS Web GUI User’s Guide
196
Copyright 2011 FUJITSU LIMITED P2X0-1090-02ENZ0
● Advanced Copy Path Status
• Local Port
The port information of the local device is displayed.
• Status
The port path status between the local and remote devices is displayed with an icon and a
character string.
- Normal
The copy path is in normal status.
- Error
The copy path is in error status
• Remote Port WWN/iSCSI Name
The port WWN or iSCSI name of the remote device is displayed.
• Detail Information
Detailed information about the copy path is displayed.
If an error occurs in the copy path, the error details or location is displayed using the following
abbreviations. If there are multiple error locations, multiple abbreviations are displayed.
- Connectable
The copy path is in normal status.
- Path Unstable
The copy path between the local device and remote device is in unstable status. For
example, link-down repeatedly occurs in a certain period of time or communication fails.
- Bitmap Resolution Mismatched
The resolution settings are different between the local and remote devices.
- D
The copy path settings may be invalid.
- N
The error occurs in the remote device.
- T
The error occurs in the FC-RA port or iSCSI-RA port on the remote device.
- C
The error occurs in the cable.
- O
The error occurs in an adapter that is not for a local or a remote device. This occurs only
when the connection type is FC-AL.
- S
The error occurs in the switch or switch settings.
- I
The error occurs in the FC-RA port or iSCSI-RA port on the local device.
- M
The error occurs in the memory.
