Chapter 11 System Management
11.2 Functions in the Action Area for System
ETERNUS Web GUI User’s Guide
458
Copyright 2011 FUJITSU LIMITED P2X0-1090-02ENZ0
11.2.3 Network Management
This section describes the network environment settings.
The following functions are available for the network environment settings:
• Setup Network Environment
• Setup Firewall
• Setup SNMP Agent Basic Interface
• Setup SNMP Agent Manager
• Setup SNMP Agent MIB Access View
• Setup SNMP Agent User
• Setup SNMP Agent Community
• Setup SNMP Agent Trap
• Download MIB File
• Send SNMP Trap Test
• Display SMTP Log
• Setup E-Mail Notification
• Setup Syslog
• Create SSH Server Key
• Create Self-signed SSL Certificate
• Create Key/CSR
• Register SSL Certificate
11.2.3.1 Setup Network Environment
This function sets up an the environment for the ETERNUS DX Disk storage system to communi-
cate with an external network.
The IP address, subnet mask, default gateway, DNS server of the ETERNUS DX Disk storage
system, and network address for the remote operation from outside of the subnet can be config-
ured. Configuration is required for each MNT, RMT and FST port.
• MNT port
The MNT port is used for general communication between the ETERNUS DX Disk storage
system and the external hosts.
• RMT port
The RMT port is used when the line must be separated from the MNT port.
• FST port
The FST port is used for maintaining the ETERNUS DX Disk storage system.
• The FST port settings are only required when the storage system is
ETERNUS DX410 S2/DX440 S2.
• When SNMP Agent Manager exists in a different subnetwork from
where the ETERNUS DX Disk storage system belongs, specify the IP
address or the network address of SNMP Agent Manager in the
"Allowed IP List" using the procedure in "11.2.3.1 Setup Network
Environment" (page 458).
• Logging on again may be required after the settings are complete.
