Chapter 11 System Management
11.2 Functions in the Action Area for System
ETERNUS Web GUI User’s Guide
459
Copyright 2011 FUJITSU LIMITED P2X0-1090-02ENZ0
The procedure to set network environment is as follows:
Procedure
1 Click [Setup Network] in [Action].
2 Specify the parameters, and click the [Set] button.
• Select Network Port
Select the port to configure from "MNT", "RMT", and "FST".
- For ETERNUS DX80 S2/DX90 S2: MNT or RMT
- ETERNUS DX410 S2/DX440 S2: MNT, RMT, or FST
• Interface
- Speed and Duplex
Select the communication speed and mode.
• Auto-negotiation
• 1Gbit/s
• 100Mbit/s Half
• 100Mbit/s Full
• 10Mbit/s Half
• 10Mbit/s Full
- Master CM IP Address
Enter the IP address for the Master CM of the ETERNUS DX Disk storage system
(required). (*1)
- Slave CM IP Address
Enter the IP address for the Slave CM of the ETERNUS DX Disk storage system.
(*1)
The IP address of the Slave CM is used when an error occurs in the Master CM.
- Subnet Mask
Enter the subnet mask of the ETERNUS DX Disk storage system (required). (*1)
- Default Gateway
Enter the IP address of the Gateway. (*1)
- Primary DNS
Enter the IP address of the Primary DNS server. (*1)
The Primary DNS server must be specified before the Secondary DNS server.
- Secondary DNS
Enter the IP address of the Secondary DNS server. (*1)
- Wake on LAN
Select whether to enable or disable the WOL function (*2).
*1: Input numeric characters ("0" - "255") for all the text boxes.
*2: The WOL function starts up the ETERNUS DX Disk storage system, which is connected to
LAN, from another server or a PC via network.
To enable or disable each service (such as HTTP and HTTPS), use the
procedure in "11.2.3.2 Setup Firewall" (page 462)
.
