■ View
The rear view of the CE that is installed in the ETERNUS DX Disk storage system is displayed.
Components that are not CMs are paled out.
The CM status is displayed with an icon.
By clicking the CM number, the [Controller Module] screen is displayed. Refer to "10.1.5
Controller Module Detail" (page 414) for display items.
10.1.6 Channel Adapter Detail
The detailed information for the Channel Adapter is displayed.
■ Summary
The following items are displayed in the Main area:
• Location
The CA installation location is displayed.
