Chapter 10 Component Management
10.1 Component Status
ETERNUS Web GUI User’s Guide
417
Copyright 2011 FUJITSU LIMITED P2X0-1090-02ENZ0
• CA Type
The CA type is displayed.
The display items in this field vary depending on the device model.
- For ETERNUS DX80 S2/DX90 S2
• 8G-FC 1port
• 8G-FC 2port
• 10G-iSCSI 1port
• 10G-iSCSI 2port
• 1G-iSCSI 1port
• 1G-iSCSI 2port
• 6G-SAS 1port
• 6G-SAS 2port
• 10G-FCoE 1port
• 10G-FCoE 2port
- For ETERNUS DX410 S2/DX440 S2
• 8G-FC 2port
• 8G-FC 4port
• 10G-iSCSI 2port
• 1G-iSCSI 2port
• 10G-FCoE 2port
• 1G-iSCSI-RA 2port
• Status
The CA status is displayed. Refer to "B.5 Component Status" (page 615)
for details.
• Status Code
The CA status code is displayed.
• Hardware Revision
The hardware version is displayed.
• Chip#n Status
The status of Chip#0 or Chip#1 is displayed. Refer to "B.5 Component Status" (page 615)
for
details.
• Chip#n Error Code
The error code for "Chip#n Status" is displayed.
• Chip#n Serial Number
The serial number of Chip#0 or Chip#1 is displayed.
• Chip#n Active EC
The Edition Control (EC) number of the currently running Chip#0 or Chip#1 is displayed.
• Chip#n Next EC
The EC number of the Chip#0 or the Chip#1 that is to be run after the next power-on is
displayed.
• Chip#n Firmware (EC1)
The firmware version that is applied to EC1 of Chip#0 or Chip#1 is displayed.
• Chip#n Firmware (EC2)
The firmware version that is applied to EC2 of Chip#0 or Chip#1 is displayed.
