Chapter 10 Component Management
10.2 Functions in the Action Area for Component
ETERNUS Web GUI User’s Guide
430
Copyright 2011 FUJITSU LIMITED P2X0-1090-02ENZ0
10.2 Functions in the Action Area for Component
When using functions in the Action area, select the desired function from the Action area that is
displayed in the status display screen.
The functions in the Action area for Component can be performed from the following display
functions:
10.2.1 Add Drive Enclosure
This function enables DEs to be added without stopping the ETERNUS DX Disk storage system.
Use GUI to install any DEs that are added.
Specify between DE#01 - DE#09 for the drive enclosures that are to be added.
The procedure to expand a DE is as follows:
1 Click [Add Drive Enclosure] in [Action].
→ The start screen appears.
Functions in the Action area for Component Display function
Add Drive Enclosure
• Drive Enclosure
Turn on Locator Beacon/Turn off Locator Beacon
• Controller Enclosure
Add Channel Adapter Port
• Channel Adapter
Assign Global Hot Spare
• Disks
Release Global Hot Spare
Assign Dedicated Hot Spare
Release Dedicated Hot Spare
Clear Disk Error Statistics (All Disks)
• Disk Error Statistics
Clear Disk Error Statistics (Selected Disks)
• This function is available only when using the ETERNUS DX80S2/DX90
S2.
• Only one DE can be added at a time.
• 2.5-inch type DEs and 3.5-inch type DEs can be installed in the same
ETERNUS DX Disk storage system.
• Be sure to use authorized expansion parts. If parts other than the
expansion parts are used, operation is not guaranteed.
• When the status of DE#01 is "Online", a DE cannot be added.
If expansion fails due to an error or problem, the expansion can be
restarted from the interrupted point by starting this function again and
recovering the failed expansion parts.
