Chapter 1 Outline
1.5 Screen Operations
ETERNUS Web GUI User’s Guide
20
Copyright 2011 FUJITSU LIMITED P2X0-1090-02ENZ0
• Total Physical Capacity
The total physical capacity of the TPPs [MB/GB/TB] is displayed. The "Total Physical Capac-
ity" is the total physical capacity of all the TPPs in the ETERNUS DX Disk storage system.
■ Snap Data Pool
The usage of SDP is displayed.
• Pie chart
The pie chart indicates the total used capacity and the total free capacity in the SDP.
Blue: Total used capacity
Gray: Total free capacity
• Snap Data Pool Count
The number of SDPs that are registered in the ETERNUS DX Disk storage system is
displayed.
• Total Used Capacity
The total used capacity of the SDP [MB/GB/TB] is displayed. The "Total Used Capacity" is the
total capacity of all the SDPs that are used for volumes.
• Total Free Capacity
The total free capacity of the SDP [MB/GB/TB] is displayed. The "Total Free Capacity" is the
total unused capacity of all the SDPs.
• Total Capacity
The total capacity of the SDP [MB/GB/TB] is displayed. The "Total Capacity" is the total
capacity of all the SDPs in the ETERNUS DX Disk storage system.
Total Free Physical Capacity = Total Physical Capacity - Total Used Physical Capacity
Total Free Capacity = Total Capacity - Total Used Capacity
