Chapter 9 Connectivity Management
9.1 Connectivity Status
ETERNUS Web GUI User’s Guide
264
Copyright 2011 FUJITSU LIMITED P2X0-1090-02ENZ0
Display Examples of Host Affinities
Display examples for the host affinity are shown in the following table.
Example
No.
Display contents Description
Host Port
Group
Host CA Port
Group
CA
Port
LUN
Group
Host
Response
Example
1
Host_
Group_
xxx
–Port_
Group_
xxx
– LUN_
Group_
xxx
Host_
Response
1
The host affinity setting has
been configured in
"Host_Group_xxx",
"Port_Group_xxx" and
"LUN_Group_xxx".
The server recognizes the
LUN group,
"LUN_Group_xxx", which
has been specified for each
member host (HBA) in
"Host_Group_xxx".
Example
2
All All Port_
Group_
yyy
– LUN_
Group_
yyy
Host_
Response
2
All servers will be covered.
The server recognizes the
specified LUN group,
"LUN_Group_yyy", from
every member port in
"Port_Group_yyy".
Example
3
– Host_z – CM#0
CA#0
Port#0
LUN_
Group_
zzz
Host_
Response
3
The host affinity setting of
"Host_z (HBA)" and
"LUN_Group_zzz" has been
configured to the device side
port, "CM#0 CA#0 Port#0".
This is an example in which
a host and a port were
directly associated using an
application other than GUI
without defining a host group
or a port group.
Example
4
–All–CM#1
CA#1
Port#1
LUN_
Group_
www
Host_
Response
4
The LUN mapping of
"LUN_Group_www" has
been configured to the
device side port, "CM#1
CA#1 Port#1".
This is an example in which
a host and a port were
directly associated using an
application other than GUI
without defining a host group
or a port group.
