CX2550 M1 Upgrade and Maintenance Manual 153
System board and components
9.2 SATA DOM
The server node can be equipped with a SATA DOM.
9.2.1 Installing the SATA DOM board
9.2.1.1 Preliminary steps
Perform the following procedures:
Ê "Disabling SVOM boot watchdog functionality" on page 54
Ê Locate the desired server with the ID button.
Ê "Shutting down the server node" on page 39
Ê If applicable, remove all external cables from the server node.
Ê "Removing the server node from the server enclosure" on page 40
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH1 / (+) No. 1 screw driver
