Figure 84: Removing the flexible tubes (A)
Ê Remove the three screws from the liquid cooling kit riser module.
Figure 85: Removing the flexible tubes (B)
Ê Pull the flexible tubes through the holes of the liquid cooling kit riser module.
10.1.2.3 Installing a liquid cooling kit
I If a new liquid cooling kit is used, a thin layer of thermal paste is applied
to the lower surface. (Remove the thermal paste protective cover.)
