10.2.2 Preparing the memory modules
10.2.2.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 54
Ê "Shutting down the server node" on page 39
Ê Disconnect the tubes from the tube system of the rack as described in the
"RackCDU
TM
Service Manual"".
Ê "Removing the server node from the server enclosure" on page 40
Ê "Removing the liquid cooling kit" on page 189
Ê "Removing memory modules" on page 124
10.2.2.2 Preparing a memory module
Figure 101: Prepared memory module
Ê Stick the cooling pad(s) on one or two sides of the memory modules, see
"Adhesive rules for the memory cooling pads" on page 200.
10.2.2.3 Concluding steps
I Before powering on the server node connect the tubes to the tube
system of the rack as described in the "RackCDU
TM
Service Manual".
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
