Ê Download the desired ESXi Recovery CD ISO image, listed under Tools.
Ê Unpack and burn the image to a CD.
Ê Ensure that no other USB storage device is connected to the server beside
the UFM.
Ê Insert the Recovery Tools CD into your CD / DVD drive and reboot the
server.
The server should now boot from the Recovery Tools CD.
Ê Follow the on-screen instructions to initiate the installation.
After the flash process is complete, you will be asked to reboot the system.
I For the Japanese market, follow the instructions provided separately.
9.3.2 Removing the UFM board
9.3.2.1 Preliminary steps
Perform the following procedures:
Ê "Disabling SVOM boot watchdog functionality" on page 54
Ê Locate the desired server with the ID button.
Ê "Shutting down the server node" on page 39
Ê If applicable, remove all external cables from the server node.
Ê "Removing the server node from the server enclosure" on page 40
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – tool-less
– Phillips PH1 / (+) No. 1 screw driver
